| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥3,100.00 | ￥3,038.00 | ￥2,945.00 | ￥2,852.00 | ￥2,790.00 |
| Noise figure | 2.5dB |
|---|---|
| Input standing wave | ≤1.5 |
| output vswr | ≤1.5 |
| Receiving frequency range | 1710-1785MHz |
| Transmission frequency range | 1805-1880MHz |
| Receive gain | 10±1.0dB |
| Emission gain | 41±1.0dB |
| Transmit maximum output power | 40±1.0dBm |
| Group delay in transmission band | ≤50ns |
| In band fluctuation | ≤2.0 dB |
| ACPR | ≤-35dBc （@±5MHz带宽） |
| Power supply requirements | ＋24Vdc |
| working temperature | -10～+55℃ |
|---|
